Wrapped Bushings Tolerances
It is not possible to accurately measure the external and internal diameters of a wrapped bushing in its free condition. In the free state, a wrapped bushing will not be perfectly cylindrical. The bushing will conform to the housing when the split is tightly closed. For this reason the OD & ID of a wrapped bushing can only be checked with special gauges and test equipment.
Below is an example on how to determine the bushing’s ID & OD tolerances with respect to the mating shaft and housing tolerances after installation:
Univega serial number year codes. ISO 286 Table Hole Tolerances Calculator; International Tolerance Grades; Variations on dimensions without tolerance values are according to ' ISO 2768'. All tolerance limits are given in mm. ISO 2768 and derivative geometrical tolerance standards are intendedto simplify drawing specifications for mechanical tolerances. Fornominalsizesbelow0.5mm,thelimitmeasuresareusuallyindicateddirectlyatthe nominalmeasure.IfgeneraltolerancesaccordingtoISO2768-1arevalid,thefollowing.
The chart and diagram shows that after installation this bushing will have a total OD tolerance of 0.030 mm. Also, the ID tolerance is 0.065 mm after installation.
Standard Bushings (non-wrapped) Tolerances
Standard bushing tolerances are specified on their respective dimension tables. For example:
If a bushing with an 8 mm ID (d) and a 12 mm OD (D) is used, the ID (d) dimension specifies an F7 tolerance which corresponds to 13 µm / 28 µm. The OD (D) dimension specifies an m6 tolerance which corresponds to 7 µm / 18 µm.
Note: Uppercase tolerances refer to different values from lowercase tolerances.
Bushing Tolerances
Wrapped Bushings
It is not possible to accurately measure the external and internal diameters of a wrapped bushing in its free condition. In the free state, a wrapped bushing will not be perfectly cylindrical. The bushing will conform to the housing when the split is tightly closed. For this reason the OD & ID of a wrapped bushing can only be checked with special gauges and test equipment.
Below is an example on how to determine the bushing’s ID & OD tolerances with respect to the mating shaft and housing tolerances after installation:
Iso 2768 Hole Tolerance For Bearing Size
The chart and diagram shows that after installation this bushing will have a total OD tolerance of 0.030 mm. Also, the ID tolerance is 0.065 mm after installation.
Standard Bushings (non-wrapped)
Standard bushing tolerances are specified on their respective dimension tables. For example:
Iso 2768 Hole Tolerance For Bearing Kit
Units: mm |
If a bushing with an 8 mm ID (d) and a 12 mm OD (D) is used, the ID (d) dimension specifies an F7 tolerance which corresponds to 13 µm / 28 µm. The OD (D) dimension specifies an m6 tolerance which corresponds to 7 µm / 18 µm.
Note:Uppercase tolerances refer to different values from lowercase tolerances.
